nRuiT Home 5Kwh Lifepo4 Deep Cycles Lithium Solar Battery for Solar System
nRuiT Home 5Kwh Lifepo4 Deep Cycles Lithium Solar Battery for Solar System
Regular price
£7,547.26 GBP
Regular price
£0.00 GBP
Sale price
£7,547.26 GBP
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Product Display
|
Technical Specification
|
||||||||||
|
Model
|
Powerporter 5.0
|
Powerporter 9.0
|
Powerporter 10
|
Powerporter 12
|
Powerporter 15
|
|||||
|
Cell Technology
|
Lithium-iron Phosphate (CATL LiFePO4)
|
|||||||||
|
Nominal Energy
|
5.1kWh
|
9.0kWh
|
10.2kWh
|
12.28kWh
|
15.46kWh
|
|||||
|
Usable Energy
|
5.0kWh
|
8.8kWh
|
10kWh
|
12.03kWh
|
15.15kWh
|
|||||
|
Round-Trip Efficiency
|
98%
|
|||||||||
|
Scalability
|
Max. 4 Modules in Parallel (Max. 60kWh)
|
|||||||||
|
Dimensions
(L/W/H)mm
|
745*460*165
|
830*460*200
|
830*460*200
|
900*460*200
|
980*460*230
|
|||||
|
Weight
|
54kg
|
75kg
|
94kg
|
112kg
|
120kg
|
|||||
|
Installation
|
Standing/Wall-Mounting
|
Standing
|
||||||||
|
Warranty
|
5 Years
|
|||||||||
|
Certification
|
CE/ UN38.3
|
|||||||||
|
Nominal Voltage
|
51.2V
|
|||||||||
|
Nominal Capacity
|
100Ah
|
175Ah
|
200Ah
|
240Ah
|
302Ah
|
|||||
|
Max. Charge Current
|
100A
|
125A
|
150A
|
150A
|
200A
|
|||||
|
Cont. Charge Current
|
50A
|
100A
|
100A
|
100A
|
200A
|
|||||
|
Max. Discharge Current
|
100A
|
125A
|
150A
|
200A
|
230A
|
|||||
|
Cont. Discharge Current
|
65A
|
100A
|
100A
|
125A
|
200A
|
|||||
|
Charge Voltage
|
51.5V~54V
|
51.5V~54V
|
51.5V~54V
|
51.5V~54V
|
51.5V~54V
|
|||||
|
Discharge Voltage
|
45V~54V
|
45V~54V
|
45V~54V
|
45V~54V
|
45V~54V
|
|||||
|
Cont.DC Discharge
|
3000W
|
5000W
|
5000W
|
5000W
|
10000W
|
|||||
|
Max.DC Discharge
|
5000W
|
10000W
|
30000W
|
|||||||
|
Cycle Life
|
≥6000 Times (90%DoD)
|
|||||||||
|
Service Life
|
10 Years
|
|||||||||
|
Protection Rating
|
IP31
|
|||||||||
|
Communication
|
CAN 2.0/ RS485
|
|||||||||
|
Charge Temperature
|
0℃~45℃
|
|||||||||
|
Discharge Temperature
|
-20℃~45℃
|
|||||||||
|
Storage Temperature
|
20℃~25℃ (Below 85% relative humidity)
|
|||||||||
|
Compatible Inverters
|
Growatt/ TBB Power/ Goodwe/ LUXPOWER/ Deye
|
|||||||||
*Original CATL *High Efficiency *High Quality Compatibility
*Flexible and Scalable *Long Lasting *Reducing Carbon Footprint
|
Model Name
|
Energy Storage Battery
|
||
|
Description
|
*This product is mainly combined with inverter, photovoltaic (PV) and related accessories to build residential energy storage system.
*The system is used to store the direct current (DC) generated by photovoltaic (PV) in the connected battery and convert the direct current (DC) generated by the connected battery into alternating current (AC) and provide it to the home grid.
(Note: The actual Residential ESS may also include electrical equipment such as distribution boxes and metering meters). *Powerporter is a Lifepo4 battery that can store electrical energy and outputs DC current. *Powerporter only maintains electrical connection with the inverter. The electrical energy generated by the PV is converted by the inverter Dc to DC and stored in the connected Powerporter. When Powerporter is needed, Powerporter’s electrical energy is converted by the inverter DC to AC and transmitted to the home grid to provide power for household appliances. |
||
|
Nominal Voltage
|
3.2V
|
||
|
Charge Cut off Voltage
|
3.65V
|
||
|
Discharge Cut off Voltage
|
2.5V
|
||
|
AC Impedance Resistance
|
≤ mΩ
|
||
|
Max Charge Current
|
|||
|
Max Discharge Current
|
|||
|
Cycle Life
|
≥
|
||
|
Charging Temperature
|
0℃~60℃
|
||
|
Discharing Temperature
|
-30℃~60℃
|
||
|
Feature 1
|
Using CATL lithium iron phosphate battery
Using CATL lithium iron phosphate battery, it has high safety performance, long cycle life, good high-temperature performance, and can be quickly charged; Large capacity, no memory effect, light weight, environmental protection.
|
||
|
New Weight
|
|||
|
Feature 2
|
Multiple protection functions
*Overchage detection functionOver discharge detection function
*Over current detection function *Short detection function *Alarm function *Balance function *Supoort RS485,CAN function *Temperature detection function |
||
|
Feature 3
|
Support 4 parallel
Support 4 parallel ,the maximum parallel capacity reaches 60kwh.
|
||
|
Feature 4
|
Many compatible brand inverter
GROWATT,Deye,Goodwe,LUXPOWER,TBB……For More Specification.
Click Here
|
||
|
Feature 5
|
High quality guaranteed
5-year warranty with guaranteed quality and service life of more than 10 years.
|
||
