Full Automatic Brick Making Machine Concrete Block Molding Machine QT5-15 Block Making Machine for Sale
Full Automatic Brick Making Machine Concrete Block Molding Machine QT5-15 Block Making Machine for Sale
Regular price
£43,348.99 GBP
Regular price
Sale price
£43,348.99 GBP
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
DIY Supplies:ELECTRICAL
Brand Name:LanYuXuan
Origin:Mainland China
Condition:New
Brick Raw Material:CONCRETE
Processing:Brick Molding Machine
Method:Hydraulic pressure
Automatic:Yes
Production Capacity (Pieces/8 hours):900-1200pcs 400x200x200/hour
Place of Origin:Shandong, China
Brand Name:HF
Voltage:Local Voltage
Dimension(L*W*H):5120x1950x2810mm
Warranty:1 Year
Key Selling Points:Long Service Life
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Marketing Type:Hot Product 2019
Warranty of core components:1 Year
Core Components:PLC, Pressure vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox
Weight (KG):5500 kg
Molding cycle:15-20s
Pallet size:1100x550mm
Rated pressure:16Mpa
Vibration frequency:2800-4200r/min
Exciting force:65-80KN
Raw material:GB steel and Manganese steel
Control Method:PLC control Unit
Vibration motor:15kwx2sets
After Warranty Service:Video technical support
Certification:CE/ISO9001
If you have any questions, please contact us ,WhatsApp:+86 13808431675,Email:1005681402@qq.com.Please ignore the shipping cost displayed on the page. Please consult me for specific shipping costs.
Production Description
QT5-15 automatic Block Making Machine
1. Particular storage and description material system insure the feeding accuracy and avoiding the effect of exterior material. So the products have high density.
2. Adopting synchronization vibration insures the products making average. The frequency can change according to different technics. Low frequency in feeding material, high frequency vibration makes the different material to have a optimal vibration way.
3. The computer is of fault diagnosis system. Warning signal is propitious to eliminate the fault. Combine with long-distance controlling system, it can achieve scrutiny, controlling, diagnosis
4. PLC intelligent control: Man-machine interface, control system equipped with complete logic control, production program, malfunction diagnosis system and remote control function. So it doesn't need a professional person but only need a simple training to the operator.
5. It produces various bricks/blocks including color-face bricks (layered material feeding),through-body tiles,lock linkage
blocks, road curb bricks, hydraulic blocks,hollow blocks, perforated bricks, and standard bricks etc.
1. Particular storage and description material system insure the feeding accuracy and avoiding the effect of exterior material. So the products have high density.
2. Adopting synchronization vibration insures the products making average. The frequency can change according to different technics. Low frequency in feeding material, high frequency vibration makes the different material to have a optimal vibration way.
3. The computer is of fault diagnosis system. Warning signal is propitious to eliminate the fault. Combine with long-distance controlling system, it can achieve scrutiny, controlling, diagnosis
4. PLC intelligent control: Man-machine interface, control system equipped with complete logic control, production program, malfunction diagnosis system and remote control function. So it doesn't need a professional person but only need a simple training to the operator.
5. It produces various bricks/blocks including color-face bricks (layered material feeding),through-body tiles,lock linkage
blocks, road curb bricks, hydraulic blocks,hollow blocks, perforated bricks, and standard bricks etc.
Main Technical Parameter
|
Qty/mould
|
5pcs/mould (hollow block 400*200*200mm)
|
|
Molding cycle
|
15s
|
|
Rated pressure
|
16MPa
|
|
Main vibration
|
Platform vibration
|
|
Vibration frequency
|
2800-4500 r/m
|
|
Power
|
26.5kw
|
|
Pallet size
|
1100x550mm
|
|
Dimension
|
6500x2350x2950mm
|
|
Host machine weight
|
7500kg
|
|
Factory Area
|
3000m²
|
Product Advantages
1. PLC control System; we select original Siemens PLC combine with independently develop machinecontrol program , assure stable and high-efficiency workingstatus.
2. Switches and motor: Adopt Japan Omron and France schneider brand ,
3. motor : we will use Siemens or ABB brand .
4. Hydraulic system : Double proportional hydraulic valve for smooth operation and long service life
5. Mould: Mnaganese steeel, deal with advanced heat treatment device assure longer mould life. and carburizing treatment will assure longer mould life span and ensure the strength of mould reach to 54-58HRC so that the mould can be used more than 100 thousand times.
6. Spare parts: follow the machine to shipment, we supply suitable wearing parts ,the after-sale services will be faster.
2. Switches and motor: Adopt Japan Omron and France schneider brand ,
3. motor : we will use Siemens or ABB brand .
4. Hydraulic system : Double proportional hydraulic valve for smooth operation and long service life
5. Mould: Mnaganese steeel, deal with advanced heat treatment device assure longer mould life. and carburizing treatment will assure longer mould life span and ensure the strength of mould reach to 54-58HRC so that the mould can be used more than 100 thousand times.
6. Spare parts: follow the machine to shipment, we supply suitable wearing parts ,the after-sale services will be faster.
Block Sample
Related Products
Our Customer
Company Profile
Qingdao HF Machinery Co., Ltd. is an industry-leading custom block machine manufacturer with a 30-year history known for designing and manufacturing innovative and unique equipment. HF has manufacturing and parts warehouses around the world, and a growing network of international representatives. As a partner, HF custom solutions fits to your company's exact needs.
FAQ
