2023 Colorful Zinc Sheet Glazed Tile Roofing Panel Roll Forming Machine Metal Roof Roll Forming Machine Profile Making Machine
2023 Colorful Zinc Sheet Glazed Tile Roofing Panel Roll Forming Machine Metal Roof Roll Forming Machine Profile Making Machine
Regular price
£103,425.99 GBP
Regular price
Sale price
£103,425.99 GBP
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Brand Name:NoEnName_Null
Origin:Mainland China
Certification:CE
Applicable Industries:Building Material Shops, Manufacturing Plant, Construction works
Condition:New
Type:Tile Forming Machine
Tile Type:Steel
Use:ROOF
Production Capacity:2-4m/min
Place of Origin:China
Voltage:380v 50 hz 3ph
Dimension(L*W*H):5.9 x 1.5x 1.2
Weight:4 kg
Warranty:1 Year
Key Selling Points:Easy to Operate
Rolling thinckness:0.3-0.8mm
Feeding width:1000
Marketing Type:New Product 2020
Warranty of core components:2 years
Core Components:Motor, PLC
Name:Colorful Zinc Sheet 828 Glazed Tile Roofing Panel Roll Forming Machine
Raw material:Galvanized Steel Sheet
Roller material:45#steel Chrome Plated
PLC:DETLA
Thickness:0.3-0.6mm
Decoiler:Manual Decoiler
Main frame:350H Steel
Feature:High Production Speed
Control system:Delta
Speed:2-4m/min
PLEASE NOTE:
1.The price only for reference, the specific cost based on your requirements and the destination port, please contact us for more product details and quotations
2.We ship you by sea !!!
3.Door to door please leave message or whatsapp or email for price !!!
Product Description
Production Flow
Main Parameter
2) Main parameter
|
ble Material |
Material |
GI, PPGI, PPGL |
|
Width |
914/1000/1200/1250mm as request |
|
|
Thickness |
0.3-0.6mm |
|
|
Material of rollers |
High grade 45# forged steel, surface hard chromium plating |
|
|
Rows of rollers |
13 stations depend on design |
|
|
Material of shafts |
High grade 45# forged steel |
|
|
Diameter of shafts |
80mm |
|
|
Material of cutting blade |
Cr12 Heat Treatment |
|
|
Cutting Mode |
Hydraulic Guide Column |
|
|
Speed |
3-4 m/min |
|
|
Side plate thickness |
16 mm |
|
|
Chain size |
1 inch |
|
|
Total power |
7.5 kw |
|
|
Voltage |
380 V 50 HZ 3 Phase |
|
|
Appearance size (About) |
6700mm*1500mm*1500mm |
|
|
Weight(About) |
3.5 tons |
|
|
Length measurement |
Encoder |
|
|
Control mode |
PLC |
|
|
Operating mode |
Button + Touch screen |
|
Hydraulic cutter :
