* Excellent performance because of an MCU intelligent control technology;
* A wide range of applicable loads because of pure sine wave AC output;
* Convenient and practical 5VDC-USB output port and 12VDC output port;
* Solar array and battery common-anode system input;
* Charge by mains supply for flexible configuration(optional function)
* Overcharge protection and overdischarge protection for a longer battery life;
* Digital meter and LEDs for visualization of operation status of the equipment;
* Overall automatic protection and alarms including AC output overload protection,short circuit protection,etc
1500w 1.5kw 24v portable all in one solar power off grid system
1500w 1.5kw 24v portable all in one solar power off grid system
Regular price
£1,289.68 GBP
Regular price
£0.00 GBP
Sale price
£1,289.68 GBP
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Product Description
Product Display
Details Images
Technical Indexes
|
Mode: AL
|
0.3kW/12V
|
0.5kW/12V
|
0.5kW/24V
|
1kW/24v
|
1.5kW/24V
|
||||||
|
Inverter
|
Battery voltage
|
12v
|
24v
|
||||||||
|
Built-in battery specification
|
1*55Ah/12V
|
2*55Ah/12V
|
4*55Ah/12V
|
||||||||
|
Rated power
|
300W
|
500W
|
500W
|
1000W
|
1500W
|
||||||
|
Output voltage
|
110/220VAC
|
||||||||||
|
Output frequency
|
50/60HZ
|
||||||||||
|
Output waveform
|
pure sine wave
|
||||||||||
|
Charge by a mains supply
|
Rated voltage
|
110/220V AC-*("*"mean an optional function)
|
|||||||||
|
Charge current
|
10A(maximum)-*(*means an optional function)
|
5A (maximum)-*(*means an optional function)
|
|||||||||
|
solar input
|
Maximum power
|
≤25V
|
≤50V
|
||||||||
|
Voltage of overcharge protection
|
10-25V
|
20-50V
|
|||||||||
|
Rated charge current
|
30A |
||||||||||
|
Maximum power
|
360Wp
|
720Wp
|
|||||||||
|
Voltage of overcharge protection
|
14.2V
|
28.4V
|
|||||||||
|
Voltage of overcharge recovery
|
14.0V
|
28.0V
|
|||||||||
|
Voltage of floating charge
|
13.7V
|
27.4V
|
|||||||||
|
DC output
|
Voltage of high-voltage protection
|
16V
|
32V
|
||||||||
|
Voltage of high voltage recovery
|
15.2V
|
30.4V
|
|||||||||
|
Voltage of low voltage recovery
|
12.6V
|
25
|
|||||||||
|
Voltage of lower voltage protection
|
11V
|
22V
|
|||||||||
|
5V DC USB output port
|
2one/max 2A
|
||||||||||
|
12V DC output port
|
2 DC ports + backboard 12V terminal block (maximum 8A)
|
||||||||||
|
Starting temperature of the exhaust fan
|
>45°C
|
||||||||||
|
Ambient temperature for operation
|
0 to 40°C
|
||||||||||
|
Ambient temperature for storage
|
-25 to 55°C
|
||||||||||
|
Operation/storage condition
|
0-90% (no condensation)
|
||||||||||
